  • FOLS-201 Handheld Fiber Optical Light Source (1310/1550nm) with 2.5mm FC/SC Connector

  • FOLS-201 Handheld Fiber Optical Light Source (1310/1550nm) with 2.5mm FC/SC Connector

  • FOLS-201 Handheld Fiber Optical Light Source (1310/1550nm) with 2.5mm FC/SC Connector

  • FOLS-201 Handheld Fiber Optical Light Source (1310/1550nm) with 2.5mm FC/SC Connector

FOLS-201 Handheld Fiber Optical Light Source (1310/1550nm) with 2.5mm FC/SC Connector

Description：

FOLS-201 Handheld Fiber Optical Light Source (1310/1550nm) with 2.5mm FC/SC Connector

Features：

Product Highlights

Stable Multi-wavelength and Single Mode Laser Output
Membrane Touch Buttons Makes It More Durable and Easier to Store
Protective Case Protects Power Meter from Being Damaged by Falling/Shocking/Wearing
LCD Backlight for Easy Operation in Darker Environments
Auto-off Function Saves the Power
See more
Consult Now

24/7 Online Consultation

Professional customer service is available to answer your questions and help you solve any problems you encounter!

Products

Specifications

Specifications
Wavelengths
1310/1550nm
Cable Type
SMF
Emitter Type
FP
Output Power
> -6dBm
Output Stability
±0.05dB/1hours or ±0.1dB/8hours
Modulation Frequencies
270Hz/1KHz/2KHz
Auto-off Function
Supported
Optical Connector
2.5mm FC/SC (Default), ST (Not included)
Spectral Width
5nm
Backlight
Supported
Power Supply
2x AA Batteries (Not included)
Relative Humidity
<90% (non-condensing)
Operating Temperature
-10 to 50°C (14 to 122°F)
Storage Temperature
-20 to 60°C (-4 to 140°F)
Dimensions(HxWxD)
6.3''x2.95''x1.26'' (160x75x32mm)
Weight
180g
*ST adapter is an optional accessory. Please contact us for separate purchase or custom configuration.

Detailed

FOLS-201 Fiber Optical Light Source

FOLS-201 optical light source is a fiber optic tester with exquisite appearance and ergonomic design. It provides 1310nm and 1550nm dual-wavelength laser output for singlemode fiber measurements, which is mainly used in FTTx networks and fiber network testing. When combine with a power meter, the instrument is called an Optical Loss Test Set, or OLTS, typically used to measure optical power and end-to-end optical loss.
